BIMeta MEP Analysis Studio: Overview

MEP Analysis Studio is a design aid for mechanical, electrical, plumbing and fire protection engineers. Run quick calculators, sketch systems on a canvas, save everything to a project and publish an HTML calculation package.

MEP Analysis Studio is a design aid. Always verify final designs against your adopted code edition.

What you can do

• About 43 calculators, e.g. Airflow from Sensible Load, Round Duct Diameter, Fan Brake Horsepower, Voltage Drop, Three-Phase Power, Demand Load, Water Heater Recovery, Rational Method Runoff, Sprinkler K-Factor, Hazen-Williams Loss, Hydrant Flow Test
• System Designer canvas: air handlers, ducts, diffusers, pumps, pipes, valves, panels, transformers, motors, lights, sprinklers and fire pumps
• Scenario Library, Equipment Library and editable Standards & Settings
• Report Studio: cover sheet, document control, calculations by discipline, equipment schedule, connection register
• Projects saved as .bimepmep files

System requirements

• Windows 10 (build 17763) or Windows 11, 64-bit
• A BIMeta account
